Dynamic system
Shantui loaders special low-speed high-torque Weichai engine, using the latest WP10H platform, advanced and reliable, strong power, efficient fuel saving, quiet and comfortable, intelligent environmental protection, compared with the WP10 platform engine fuel consumption reduced by 10%;
Set no-load, medium-load, heavy-load three-level power control mode to meet the needs of different working conditions, low comprehensive fuel consumption;
Water level alarm function, reminding users to release water in time to further improve the reliability of the machine;
The 300L large-capacity diesel tank is placed behind to meet the needs of continuous operation, and the stability of the whole machine is greatly improved.



Transmission system
Tailor-made for the mountain push loader, specially designed planetary transmission, speed increased by 10%, traction increased by 10%, comprehensive operation efficiency increased by more than 15%;
Through the perfect match with the engine, torque converter, drive shaft, drive axle, achieve the maximum working efficiency, good acceleration performance, fast speed;
Combined working conditions (walking and action at the same time) large traction and lifting force, strong explosive force, high working efficiency.
Structural member
The use of reinforced structure front and rear frame, high strength, long life; Wheelbase up to 3300mm, more stable operation;
The large open hinge structure has the advantages of stress dispersion, easy maintenance and strong load resistance. The upper hinge adopts double tapered roller bearing, which has greater load bearing capacity and is more suitable for harsh working conditions. Articulated alignment design, the front and rear tire movement track is the same, reduce steering resistance, reduce energy consumption and extend tire life;
Optimized design of efficient connecting rod mechanism, fast action, large digging force, up to 185KN, strong lifting ability; Increase the low discharge Angle, improve the discharge performance of site operation, suitable for low discharge conditions; High strength design of the working device, pin increase, eliminate local weakness, ensure to meet all kinds of harsh working conditions;
Rich working device configuration, can meet the needs of various working conditions. Bucket strengthening and modification, greatly improve the full bucket rate.
Electrical system
Intelligent and reliable new step digital combined instrument, easy to read vehicle information, timely and accurate real-time vehicle information, to achieve fault self-test and alarm, to ensure the efficient and safe operation of the host;
Independent bending column, more comfortable operation;
The integrated relay box and safety box are easy to repair and have more reliable performance.
Variable speed control two forward one back, working device control can be selected mechanical or pilot type; Chinese voice alarm, gas horn, improve safety (more suitable for vehicles, crowded places);
LED front and rear working lights, strong light, long life, LED reading lights in the cab, entertainment sound system.
Maintenance convenience
The air storage cylinder is placed on the right side of the ladder, and the drainage is simple and convenient;
Centralized lubrication, the pin steel sleeve with butter standing on the ground can be completed;
The whole system adopts large opening side shield, large maintenance space, smooth and convenient maintenance channel;
Air filter, wood filter, machine filter, transmission fine filter is within reach, but also with fuel level alarm function, to remind the driver of daily water maintenance, protect the engine.
