Performance parameter |
Product model |
SK105 |
Size parameters |
|
Vehicle external dimensions (mm) |
9500*3760*4250 |
wheelbase (mm) |
3950+1750 |
Minimum ground clearance(mm) |
375 |
Quality parameters |
|
Rated load(kg) |
70000 |
Vehicle preparation quality (kg) |
37400 |
Performance parameters |
|
Maximum speed (km/h) |
40 |
Maximum climbing slope (%) |
33 |
Engine |
|
Model number |
WP14TG765E304 |
Rated power(kw/rpm) |
562/1900 |
Gearbox |
|
Model number |
8DS240A |
axle |
|
Front axle |
25 |
Rear axle |
40+40 |
wheel |
|
Tyre type |
16.00R25 |
top |
|
volume((m³) |
39 |
Zorry and concrete For a long time, Shantui has continued to pay attention to environmental protection and sustainable social development. From the mining of concrete raw materials to concrete mixing, transportation, construction waste treatment and regeneration, Shantui has integrated construction equipment and technical solutions for the whole life cycle of quarrying and concrete, which can provide technical and equipment support for the sustainable development of quarrying and concrete industry.
Airport Shantu intelligent integrated construction platform and perfect integrated construction equipment for road construction: bulldozer, grader, paver, single steel wheel, double steel wheel, tire roller, mixing station, etc. Through the use of intelligent integrated construction technology, it realizes digital site management and construction, real-time monitoring of construction progress and quality, maximizes the quality and efficiency of construction, and meets the high-precision construction requirements of the airport runway.
The power is surging. It is equipped with Weichai WP13 engineering version engine with a torque of up to 2300N·m, with strong power, better reliability and lower fuel consumption: · Large diameter cooling fan + plate-fin large cooling module, strong environmental adaptability, suitable for high-load and heavy-load uphill operation in mining areas: · Desert air filter total Cheng, extend the maintenance cycle: · Meet the non-road phase IV emission standards! · Mining truck exclusive WP engineering version engine + small speed ratio transmission + high speed ratio two-stage deceleration double drive axle power chain, higher reliability, more economical: · Pull-type diaphragm spring ceramic clutch, vehicle shift smooth and non-slip.
Strong bearing capacity · high-strength main and secondary flexible frame, optimize the centralized force position structure of the frame through finite element analysis, achieve uniform load distribution, reduce stress concentration, improve frame life · skateboard spring suspension structure, continuous operation for 12 months without failure; enhanced maintenance-free balance shaft, extremely high reliability · thrust rod adopts V-type structure layout and maintenance-free ball hinged ball head structure, good cushioning effect; · high-speed ratio two-stage deceleration drive bridge, using high-strength materials applied to hub bridge shell and other parts; · 16.00R25 engineering pattern tire, strong bearing capacity, small tire sinking capacity: armored full protection + enhanced upper protection + strengthening stone drill.
Mature and reliable. Weichai engine, international leading technology, high reliability: · WP13+Fast 8DS240A+ Hand casting heavy-duty mining axle combination is mature and reliable; ·Fast 8DS series single main box transmission, reducing fault points; forced lubrication, extended life; super strong key gears and bearings · The most similar models with high reliability of Hand axle: · The first single-sided skeleton skin structure in China, the cab is bright and open, and the space is large, which maximizes the improvement of vision and increases the front protection device to effectively protect the driver; standard full hydraulic steering, comfortable and light driving.
Economic efficiency, loading power, flat-mounted 39m3, stacked 46m3, the whole fleet adopts mountain push 105 mine card, and the transportation efficiency can be improved by more than 10% compared with competing products: · small speed ratio gearbox + high speed ratio rear axle + small angle drive shaft layout, "two small and one big" achieves higher reliability, larger The torque of torsion! Lower transportation unilateral fuel consumption provides excellent comprehensive benefits for end users · three-stage desert air filter, small air resistance, high efficiency, good filtration, reduce maintenance costs: · high refueling port and high volume fuel tank to ensure the uninterrupted operation of the vehicle throughout the day.
